35mm Orange Circular Power Cable Unarmoured 4 Core & Earth XLPE/PVC 1000mtr
Loading...
Description
Circular Power Cable, Unarmoured, 4 Core & Earth, 35 mm, Plain Annealed copper, 0.6/1 kV, 19/1.53 mm Strands, 7.7 mm Nominal Diameter, 10 mm Earth Conductor, 28.1 mm Overall Diameter, 170 mm Bend Radius, 0.9 mm Insulation Thickness, Conductor Resistance: DC - 0.524 Ohm/km, X-90 XLPE Insulation, 5V-90 PVC Sheath, Red White Blue Black Green/Yellow Cores, Orange Sheath, -15 to 90 deg C, AS/NZS 5000.1
Key Specifications
| Barcode (EAN-13) |
9310835052954
|
|---|---|
| SKU |
CBL35/4CEOCXLPE/PVC-5
|
| Brand |
Generic
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 500 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 20199730 |
